JVC KW-V235DBT User Manual

36
OTHER EXTERNAL COMPONENTSOTHER EXTERNAL COMPONENTS
Using the rear view camera
• To connect a rear view camera, see page66.
• To use a rear view camera, a REVERSE lead
connection is required. (Page 64)
❏ Settings for the rear view camera
1 Display the <Settings> screen.
On the Home screen:
KW-V330BTKW-V230BT
KW-V235DBT
2 Display the <Input> setting screen.
3 Display the <Rear Camera> screen.
4
[ON] Displays the picture from the rear view
camera when you shift the gear to the
reverse (R) position.
[OFF] Select this when no camera is
connected
❏ Displaying the rear view camera screen
To display the picture from the rear view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• To remove the caution message, touch the screen.
To display the picture from the rear view camera
manually
KW-V330BT
KW-V230BT
KW-V235DBT
• Only for KW-V230BT/KW-V235DBT: You can also
display the picture from the rear view camera
by selecting [Camera] on the pop-up short-cut
menu (Page11).
To exit the camera screen
Press HOME on the monitor panel.
• You can also exit the camera screen by touching
the area shown below.
2017KW-VEntryE.indb362017KW-VEntryE.indb36 2016/09/2717:412016/09/2717:41

JVC KW-V235DBT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
DIN size	2 DIN
Product color	Black
Disc types supported	CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Display diagonal	6.2 \
Key illumination color	White
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	DAB, FM, LW, MW
Preset stations quantity	20
Package weight	3100 g

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	182 x 160 x 111 mm
