JVC KW-V235DBT User Manual

38
OTHER EXTERNAL COMPONENTSOTHER EXTERNAL COMPONENTS
Using external audio/video
players—AV-IN
When the operation buttons are
not displayed on the screen, touch
the area shown on the illustration.
• To change settings for video
playback, see page 52.
❏ Starting playback
Preparation:
“AV-IN” cannot be selected when <iPod Setup>
is set to [USB+AV-IN]. Be sure to select [USB 1
Wire] for <iPod Setup> beforehand. (Page21)
1 Connect an external component to the
iPod/AV-IN input terminal. (Page
66)
2 Select “AV-IN” as the source. (Page10)
3 Turn on the connected component and
start playing the source.
❏ Changing the AV-IN name
You can change the AV-IN name displayed on the
“AV-IN” source control screen.
1 Display the <VIDEO Mode> screen.
2 Select an AV-IN name.
• This setting does not affect the source name
displayed on the Home screen.
2017KW-VEntryE.indb382017KW-VEntryE.indb38 2016/09/2717:412016/09/2717:41

JVC KW-V235DBT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
DIN size	2 DIN
Product color	Black
Disc types supported	CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Display diagonal	6.2 \
Key illumination color	White
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	DAB, FM, LW, MW
Preset stations quantity	20
Package weight	3100 g

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	182 x 160 x 111 mm
