ENGLISH 49

SETTINGSSETTINGS

Sound adjustment

❏ Using the sound equalization

• The adjustments are memorized for each source

until you adjust the sound again. If the source is

a disc, the adjustments are stored for each of the

following categories.

– DVD/VCD

–CD

– DivX/MPEG1/MPEG2/MP3/WMA/WAV/AAC/

FLAC

• You cannot adjust the sound when the unit is in

standby.

Selecting a preset sound mode

1 Display the <Settings> screen.

On the Home screen:

KW-V330BTKW-V230BT

KW-V235DBT

2 Display the <Equalizer> screen.

3 Select a sound mode.

• You can also display the <Equalizer> screen as

follows:

– For KW-V230BT/KW-V235DBT: Press [

] on

the source control screen.

– For KW-V330BT: Select [

] on the pop-up

short-cut menu (Page11).

Storing your own adjustments—Adjusting the

sound precisely

1 Select a sound mode. (See the left column.)

2 Select a band and adjust the level of the

selected band.

• You can adjust the level by dragging the slider

or using [J]/[K].

• Repeat this step to adjust the level of other

bands.

The adjustments are stored and <User> is

activated.

3 Adjust the sound.

<Q factor> Adjusts the width of the

frequency.

<Bass EXT> Activates ([ON])/deactivates

([OFF]) bass.

<SW LEVEL> Adjusts the subwoofer level.*

• To apply the adjusted equalizer to all playback

sources, press [ALL SRC], then press [OK] to

confirm.

• To clear the adjustment, press [EQ INIT].

* Not adjustable when <None> is selected for subwoofer on the

<Speaker Select> screen. (Page50)

❏ Setting the crossover network mode

Select the appropriate crossover network mode

according to the speaker system (2-way speaker

system or 3-way speaker system).

1 Turn off the AV source. (Page7)

2 Display the <X’over Network> screen.

• For KW-V230BT/KW-V235DBT: Press and

EQ on the monitor panel at the same time.

• For KW-V330BT: Press

and on the

monitor panel at the same time.

3 Select the crossover network mode.

[2way] Select this when connecting speakers

in a 2-way system (front/rear).

[3way] Select this when connecting speakers

in a 3-way system (tweeter/mid

range/woofer).

A confirmation message appears. Press [Yes].

2017KW-VEntryE.indb492017KW-VEntryE.indb49 2016/09/2717:412016/09/2717:41

Questions and Answers:

Need help?

Do you have a question about the JVC KW-V235DBT and is the answer not in the manual?

JVC KW-V235DBT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
DIN size	2 DIN
Product color	Black
Disc types supported	CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Display diagonal	6.2 \
Key illumination color	White
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	DAB, FM, LW, MW
Preset stations quantity	20
Package weight	3100 g
