JVC MX-D302T User Manual

3
Getting Started
Accessories
Check that you have all of the following items, which are supplied with the System.
AM Loop Antenna (1)
Remote Control (1)
Batteries (2)
FM Wire Antenna (1)
If any of these items is missing, contact your dealer immediately.
How to Put Batteries in the Remote
Control
Match the polarity (+ and –) on the batteries with the + and – markings in the battery compartment.
CAUTION: Handle batteries properly.
To avoid battery leakage or explosion:
• Remove batteries when the Remote Control will not be used for a long time.
• When you need to replace the batteries, replace both batteries at the same time with new ones.
• Do not use an old battery with a new one.
• Do not use different types of batteries together.
Using the Remote Control
The Remote Control makes it easy to use many of the functions of the System from a distance of up to 7m
(23 feet) away.
You need to point the Remote Control at the remote sensor on the System’s front panel.
R6P (SUM-3)/AA (15F)
DISC
DISC
DISC
REPEAT
RANDOM
CONTINUE
Remote sensor
EN.MX-D302T[J]/f 98.1.13, 5:05 PM3

JVC MX-D302T Specifications

Amplifier Section

output power	55 watts per channel
input sensitivity	300 mV
input impedance	50 kohms

Cassette Deck Section

frequency response Type II	50 - 14, 000 Hz
frequency response Type I	50 - 14, 000 Hz
wow and flutter	0.15% (WRMS)

CD Automatic Changer Section

cd capacity	3 discs
dynamic range	85 dB
signal-to-noise ratio	90 dB

Tuner Section

fm tuning range	87.5 - 108.0 MHz
am tuning range	530 - 1, 710 kHz
dimensions	265 × 315 × 340 mm

Speaker Specifications

tweeter size	5 cm
woofer size	12 cm
power handling capacity	60 W

Power Specifications

power requirements	AC 120 V, 60 Hz
power consumption	95 watts
standby power consumption	9 watts

Weight and Dimensions

dimensions	265 × 315 × 340 mm
mass	7.2 kg
speaker dimensions	215 × 315 × 230 mm
