JVC TK-C685E User Manual

38
Changing camera settings from remote control
(● indicates the default value)
(● indicates the default value)
LANGUAGE Setting
Item Setting value Functions and settings
LANGUAGE ● ENGLISH
FRENCH
GERMAN
SPANISH
ITALIAN
For selecting the menu’s display language.
CAMERA FUNCTION1
screen
Item Setting value Functions and settings
V.P HA SE –156 to 0 to 156
(● 0)
This adjusts the vertical synchronization to those of other cameras when a
selector switch for the synchronizing system on the Ceiling Mount is at LL. (50
Hz power region only.)
POS.TITLE LOC. ● UP-L
DOWN-L
UP-C
DOWN-C
UP-R
DOWN-R
This item sets the display position of the position title and area title.
UP-L : Display at the top left of the screen.
DOWN-C : Display at the bottom center of the screen.
DOWN-L : Display at the bottom left of the screen.
UP-R : Display at the top right of the screen.
UP-C : Display at the top center of the screen.
DOWN-R : Display at the bottom right of the screen.
PRIVATE MASK.. ^ This function allows you to set and mask areas that you do not wish to display in
the recorded screen.
The selected areas move together with the pan, tilt and zoom operations.
[Private Mask Setting] (A Page 54)
MODE ● OFF
ON
This item sets the ON/OFF setting of the Private Mask.
OFF : Private Mask is disabled.
ON : The [MASK MODE] screen is displayed. Select the Mask No., set to
AONB and set the mask. See [Private Mask Setting] (A Page 54) for
details of the settings.
BRIGHT 0 to 10
(● 4)
This item sets the color of the mask.
A0B is black. The larger the number is, the closer the color is to white.
When the number is A10B, the color is white.
MANUAL DISPLAY OFF
● ON
When the remote control unit is used for manual operation other than preset
positions, this item sets whether to display AMANUALB on the screen.
If AONB is selected, AAUTO PANB and AAUTO TRACE..B will be displayed
respectively on the screens during auto pan and auto trace operation.
ON : Manual will be displayed.
OFF : Manual will not be displayed.
Memo :
● When this item is set to AONB, Manual will not be displayed during selection of
preset position if the [AREA DISPLAY] item (A Page 42) is set to ATITLEB or
ADIRB.
