Technical Data
Operating Instructions for Powador .-. TL_EN Page
EN
Input levels 40.0 TL3 48.0 TL3
Park
60.0 TL3 72.0 TL3
Park
DC MPP range from [V] to [V]* 350 ... 800 410 ... 800 480 ... 850 580 ... 850
Operating range from [V] to [V] 200 ... 800 200 ... 800 200 ... 850 200 ... 850
Starting voltage [V]** 250
Open circuit voltage [V] 1 000 (start to 950)
Rated current max. [A] 3 x 34.0 3 x 34.0 3 x 36.0 3 x 36.0
Max. power per tracker [W] 20,000 20,000 20,000 24,000
Number of strings 3 x 1 (M)
3 x 4 (XL)
3 x 1 (M)
3 x 4 (XL)
3 x 1 (M)
3 x 4 (XL)
3 x 1 (M)
3 x 5 (XL)
3 x 4 (F)
Number of MPP trackers 3
Polarity safeguard Short-circuit diode
*At DC voltages below the MPP range the maximum rated current reduces the maximum input power.
**For PV generators with MPP voltages below the MPP range of the inverter: set the start voltage in the menu.
Output levels
Rated power [VA] , 40,000 49,900 60,000
Grid voltage [V] 230 / 400 277 / 480*** 230 / 400 277 / 480***
Rated current [A] x . 3 x 48.1 3 x 72.2 3 x 72.2
Rated frequency [Hz] 50/60
cos phi 0.80 inductive to 0.80 capacitive
Number of feed-in phases 3
Distortion factor [%] < 3
***Device is designed for use exclusively on the medium-voltage grid.
General electrical data
Max. eciency [%] 98.0 98.0 97.9 98.3
European eciency [%] 97.8 97.9 97.7 98.0
Make current [A] / ON duration [ms] 98 / 4.4
Internal consumption: standby [W] < 30
Internal consumption: night [W] ~1.5
Feed-in starts at [W] 120
Circuit design IGBT, self-commutated, transformerless
Grid monitoring Country-specic
CE conformity Yes
Table 2: Electrical data
