. Position and secure the device
WARNING
Impact hazard, risk of breakage to the inverter
› Pack the inverter securely for transport.
› Carefully transport the inverter using the built-in eyebolts!
CAUTION
Risk of injury if the inverter tips over!
Risk of tipping due to high centre of gravity, particularly with the housing doors open.
› Anchor the inverter securely to the ground immediately after positioning it and, if possible, fasten
it to the wall.
› Do not open the housing doors until the inverter has been securely anchored.
.-. TL F=. kN
.-. TL F=, kN



Figure : Transport device Figure : Transportation of the inverter
Key
1 Shackle 3 Centre of gravity
2 Transportation rope
Position device
. Heave the eyebolts for the hoist.
. Connect the shackles to the eyebolts.
. Hang the transportation rope through the shackle.
. Attach a transportation rope to a stable hoist. (>  kN)
. Raise the device.
. Transport to the place of assembly (keep an eye on the centre of gravity!)
. Lash the device securely on the ground.
» Install and secure the inverter.
