- 10
1 Filling hole motor oil (top)
2 Filling hole motor oil (lateral)
3 Oil dip (engine)
4 Oil filter (engine)
5 Oil drain screw engine
6 Water separator
7 Fuel filter
8 Filling hole transmission oil incl. venting
9 Oil drain screw intermediate gear
10 Oil sight glass intermediate gear
11 Oil drain screw pump
12 Fine filter
13 Oil tank
14 Frost protection rinsing valve
15 Pressure switch
16 Overflow valve
17 Safety block burner
18 Detergent inlet
19 Fuel filter
20 Starter
21 Alternator
22 Dirt outlet at the air filter
23 Air filter
24 Air filter insert
Care and maintenance
2
3
4
67
12
11
1
8
16
23
20
10
21
22
5
1315
24
14
HDS 17/20
HDS 13/20
HDS 13/35
HDS 9/50
18
9
17
19
30 EN
