KEB combivert B6 User Manual

GB - 22
CP-Parameter
5. Parameter Description
CP-Parameter
1)
Setting Range
Resolu-
tion
Default Unit
2)
↵
3)
Based
on
CP.00 Password input 0…9999 1 – – – ud.01
CP.01 Actual frequency display -400…400 0.0125 0 Hz – ru.03
CP.02 Set frequency display -400…400 0.0125 0 Hz – ru.01
CP.03 Inverter status 0…255 1 0 - – ru.00
CP.04 Apparent current 0…6553.5 0.1 0 A – ru.15
CP.05 Apparent current / peak value 0…6553.5 0.1 0 A – ru.16
CP.06 Utilization 0…65535 1 0 % – ru.13
CP.07 DC link voltage 0…1000 1 0 V – ru.18
CP.08 DC link voltage / peak value 0…1000 1 0 V – ru.19
CP.09 Output voltage 0…778 1 0 V – ru.20
CP.10 Minimal frequency 0…400 0.0125 0 Hz – op.06
CP.11 Maximum frequency 0…400 0.0125 70 Hz – op.10
CP.12 Acceleration time 0.00…300.00 0.01 5 s – op.28
CP.13 Deceleration time (-0.01=CP.12) -0.01…300.00 0.01 5 s – op.30
CP.14 S-curve time off; 0.01…5.00 0.01 off s – op.32
CP.15 Boost 0.0…25.5 0.1 LTK % – uf.01
CP.16 Rated frequency 0…400 0.0125 50 Hz – uf.00
CP.17 Voltage stabilization 0…649, off 1 off V E uf.09
CP.18 Switching frequency 0…LTK 1 LTK – E uf.11
CP.19 Fixed frequency 1 -400…400 0.0125 5 Hz – op.21
CP.20 Fixed frequency 2 -400…400 0.0125 50 Hz – op.22
CP.21 Fixed frequency 3 -400…400 0.0125 70 Hz – op.23
CP.22 DC braking / mode 0…9 1 7 – E pn.28
CP.23 DC braking / time 0.00…100.00 0.01 10 s – pn.30
CP.24 Max. ramp current 0…200 1 140 % – pn.24
CP.25 Max. constant current 0…200 1 200:off % – pn.20
CP.26 Speed search / condition 0…15 1 8 – E pn.26
CP.27 Motor protection / response 0…6 1 6 – – pn.14
CP.28 Motor protection / mode 0…1 1 1 – – dr.11
CP.29 Motor protection / rated current 0.0…370.0 0.1 LTK A – dr.12
CP.30 Analog output / function 0…26 1 2 – E an.31
CP.31 Analog output / amplication -20.00…20.00 0.01 1 – – an.33
CP.32 Transistor output / function 0…80 1 20 – E do.00
CP.33 Relay output / function 0…80 1 4 – E do.02
CP.34 Relay output / switching level ±30000.00 0.01 100.00 – – le.02
CP.35 Set value selection 0…2 1 0 – E an.00
CP.36 Select 50/60Hz mode
4)
0…1 1 0 – E ud.06
1)TheCP-Parametergroupisaselectionofmorethan500parametersand8parametersetsforsimpleapplications.
EachCP-Parameter(notCP.00)canbeindividuallyassignedsoaspecialnalcustomermenueisgenerated.
Furtherdocumentationisspeciedattheendofthismanual.
2)ENTERparametersee4.2.1
3)Theoriginparametersareindicatedintheservicemenue(CP_SE)andintheapplicationmenue.
4)OnlyhousingB
