KEB COMBIVERT F4-F Applications Manual

5
ANTRIEBSTECHNIK
6
12 5
KEB COMBIVERT F4-F
Name: Basis
15.03.99
6
Section PageDate
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter
Functional DescriptionCP-Parameter Definition
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
6.12.4 Example
For example a user menu shall be programmed with following characteristics:
1. Display of actual frequency (ru.1) in the respective set
2. Absolute digital setpoint setting (SP. 1) in set 2
3. Absolute digital setpoint setting (SP. 1) in set 3
4. Acceleration and deceleration time (SP.11/SP.12) in the respective active set
5. On switch on the active parameter set (ru.18) shall be displayed
1.) ud.15 = 2001 ; Parameter address for ru.1
ud.16 = A ; Display in the active set
2.) ud.17 = 3001 ; Parameter address for SP. 1
ud.18 = 2 ; Preadjustment in set 2
3.) ud.19 = 3001 ; Parameter address for SP. 1
ud.20 = 3 ; Preadjustment in set 3
4.) ud.21 = 300B ; Parameter address for SP.11
ud.22 = A ; Preadjustment in the respective set active at the time
ud.23 = 300C ; Parameter address for SP.12
ud.24 = A ; Preadjustment in the respective set active at the time
5.) ud.27 = 2012 ; Parameter address for ru.18
ud.28 = A ; Display in the active set
ud.2 = 1 ; Disply of ru-Parameter (by activating the CP-mode this
; this setting is ignored)
ud.3 = 7 ; Display of CP.7
adjust all other parameter addresses to „off“ so that no indication occurs.
6.12.5 Used Parameters
ud.0 2600h ✔ - ✔ 0 9999 1 cp_on -
ud.1 2601h ✔ - - -32767 32767 1 cp_on only visible by bus
ud.2 2602h ✔ - - 1(ru) 16(Pd) 1 1 (ru) ru/SP/Pn/dr/cs/ds/ud/Fr/An/di/do/LE/In/Sn/Pc/PdAA
ud.3 2603h ✔ - - 0 *255 *1 1 * dependent on parameter group
ud.13 260Dh - - - - - - - only visible by bus
ud.14 260Eh - - - - - - - only visible by bus
ud.15 260Fh ✔ - ✔ -1 (off) 7FFF 1 2001 corresponds to ru.1
ud.16 2610h ✔ - ✔ 0 8 1 0 set 0...7; A(8) = active set
