KEB COMBIVERT F4-S/1.2 User Manual

Installation and Connection
10
2.5.2 Digital Inputs
4 5 11 12 13 14
PE
4 6 12 13 14
PE
+
5
2.5.3 Analog Inputs
789 PE
REF
3...10 k
Ω
ΩΩ
Ω
/ 0.5 W
89
+-
SPS
PE
REF
0...10V Ri
≈
≈≈
≈
56 kOhm
Analog inputs that are not used must be connected to the earth reference. To prevent
undefined conditions during external supply, make sure to switch on the supply first
and then the inverter.
2.5.4 Outputs
Analog Output:
0...10V DC when Ri
≥
≥≥
≥
56 k
Ω
ΩΩ
Ω
const.
0...1mA DC when Ri
≤
≤≤
≤
5k
Ω
ΩΩ
Ω
const.
0 or 10V as digital output (An.14 = 7).
Relay RLA/B/C
Internal Voltage
Supply
External Voltage
Supply
Internal Voltage
Supply
External Voltage
Supply
123 910
+
PE
