KEB COMBIVERT F4-S/1.2 User Manual

Parameter Tables
84
6.11 do-Parameter
6.12 LE-Parameter
Size No. Name Adr.
(hex)
P E ro Res. Lower
Limit
Upper
Limit
Default
Value
Unit
do 0 Output Logic 2A00
••
103 0
do 1 Output Condition 1 2A01
••
1 0 24 14
do 2 Output Condition 2 2A02
••
1024 2
do 9 Select Out 1 Condition 2A09
••
103 2
do 10 Select Out 2 Condition 2A0A
••
103 1
do 17 Out 1 Condition Logic 2A11
••
103 0
do 18 Out 2 Condition Logic 2A12
••
103 0
do 25 Out Condition Logic 2A19
••
103 0
Size No. Name Adr.
(hex)
P E ro Res. Lower
Limit
Upper
Limit
Default
Value
Unit
LE 0 Frequency Level 1 2B00
•
0,0125 0 409,58 0 Hz
LE 1 Frequency Level 2 2B01
•
0,0125 0 409,58 4 Hz
LE 8 Load Level 1 2B08
•
1 0 200 50 %
LE 9 Load Level 2 2B09
•
1 0 200 100 %
LE 16 Active Current Level 1 2B10
•
0,1 0 370 0 A
LE 17 Active Current Level 2 2B11
•
0,1 0 370 0 A
LE 32 OL-Warning Level 2B20
•
1 0 100 80 %
LE 36 Frequency Hysteresis 2B24 0,0125 0 20 0,5 Hz
