Kenwood DPX-M3200BT User Manual

22
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
[SUBWOOFER SET] [ON]: Turns on the subwoofer output. ; [OFF]: Cancels.
[FADER]
(Not applicable if 3-way crossover is selected.)
[R15] to [F15] ([0]): Adjusts the front and rear speaker output balance.
[BALANCE]
[L15] to [R15] ([0]): Adjusts the left and right speaker output balance.
[VOLUME OFFSET]
[–15] to [+6] ([0]): Presets the initial volume level of each source by
comparing to the FM volume level.
(Before adjustment, select the source you want to adjust.)
[SOUND EFFECT]
[SOUNDRECNSTR]
(Sound
reconstruction)
(Not applicable for RADIO source and AUX source.)
[ON]: Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression. ; [OFF]: Cancels.
[SPACE ENHANCE]
(Not applicable for RADIO source.)
[SMALL]/[MEDIUM]/[LARGE]: Virtually enhances the sound space. ;
[OFF]: Cancels.
[SND REALIZER]
[LEVEL1]/[LEVEL2]/[LEVEL3]: Virtually makes the sound more
realistic. ; [OFF]: Cancels.
[STAGE EQ]
[LOW]/[MIDDLE]/[HIGH]: Virtually adjusts the sound position heard
from the speakers. ; [OFF]: Cancels.
[DRIVE EQ]
[ON]: Boosts the frequency to reduce the noise heard from outside the
car or running noise of the tyres. ; [OFF]: Cancels.
[SPEAKER SIZE]
Depending on the crossover type you have selected (see “Change the
crossover type” on page 7), 2-way crossover or 3-way crossover
setting items will be shown. (See the following “Crossover settings”.)
By default, 2-way crossover type is selected.
[X ‘ OVER]
[DTA SETTINGS]
For settings, see “Digital Time Alignment settings” on page 24.
[CAR SETTINGS]
Audio Settings
• For 2-way crossover: [SUB-W LEVEL] / [SUBWOOFER SET] is selectable only if
[SWITCH PREOUT] is set to [SUBWOOFER] . (Page 6)
•
[SUB-W LEVEL] is selectable only when [SUBWOOFER SET] is set to [ON] .
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
SPEAKER SIZE
Selects according to the connected speaker size for optimum performance.
• The frequency and slope settings are automatically set for the crossover of
the selected speaker.
• If
[NONE] is selected for the following speaker in [SPEAKER SIZE] , the [X ‘ OVER]
setting of the selected speaker is not available.
– 2-way crossover:
[TWEETER] of [FRONT] / [REAR] / [SUBWOOFER]
– 3-way crossover: [WOOFER]
X ‘ OVER (crossover)
•
[FRQ] / [F-HPFFRQ] / [R-HPFFRQ] / [SWLPF FRQ] / [HPFFRQ] / [LPFFRQ] : Adjusts the
crossover frequency for the selected speakers (high pass filter or low pass
filter).
If
[THROUGH] is selected, all signals are sent to the selected speakers.
•
[SLOPE] / [F-HPFSLOPE] / [R-HPFSLOPE] / [SWLPF SLOPE] / [HPFSLOPE] / [LPFSLOPE] :
Adjusts the crossover slope.
Selectable only if a setting other than
[THROUGH] is selected for the
crossover frequency.
•
[SW LPF PHASE] / [PHASE] : Selects the phase of the speaker output to be in line
with the other speaker output.
•
[GAINLEFT] / [GAINRIGHT] / [F-HPFGAIN] / [R-HPFGAIN] / [SWLPF GAIN] / [GAIN] : Adjusts
the output volume of the selected speaker.
JS_KWD_DPX_M3200BT_MN_EN00.indd 22JS_KWD_DPX_M3200BT_MN_EN00.indd 22 9/11/2019 3:52:19 PM9/11/2019 3:52:19 PM

Kenwood DPX-M3200BT Specifications

General

USB version	2.0
ISO connector	Yes
Bluetooth range	10 m
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, PBAP
Line outputs (RCA)	2
USB ports quantity	1
DIN size	2 DIN
Impedance	40 Ω
Clock mode	24h
Output power	50 W
Product color	Black
Volume control	Touch
Frequency range	30 - 15000 Hz
Disc types supported	-
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	40 dB
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Display type	LCD
On Screen Display (OSD) languages	DUT, ENG, ESP, FRE
Cables included	DC
Operating temperature (T-T)	-10 - 60 °C
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	24

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	111 mm
Weight	1700 g
