8
Screw the antenna into the
connector on the top of the
transceiver by holding the antenna
at its base and turning it clockwise
until secure.
Note:
The antenna is neither a
handle, a key ring retainer, nor a
speaker/ microphone attachment
point. Using the antenna in these
ways may damage the antenna
and degrade your transceiver’s
performance.
INSTALLING THE BELT CLIP
If necessary, attach the belt clip
using the two supplied
3 x 8 mm screws.
Note:
If the belt clip is not installed,
its mounting location may get hot
during continuous transmission
or when left sitting in a hot
environment.
INSTALLING THE (OPTIONAL) ANTENNA
Do not use glue which is designed to prevent screw loosening when
installing the belt clip, as it may cause damage to the transceiver.
Acrylic ester, which is contained in these glues, may crack the
transceiver’s back panel.
S
A
B
C
1
MIC
<
>
To Next Page
