B3000 SERVICE MANUAL
60-200807-000, REV C 74
The B3000 Coin Changer Accessory:
The B3000 Coin Changer Accessory is custom designed to be used exclusively with the B3000
Commercial Brewer and the aforementioned coin mechanism. All the necessary hardware and cables
for assembling the B3000 Coin Changer Accessory are included. See figures 1 and 2. The items
included in the accessory kit are:
1. Coin changer cabinet
2. Brewer coin platform
3. High capacity platform
4. Brewer-cabinet plate
5. Accessory package
A. Screws 5 ea.
B. Control cable
C. Keys 2 ea.
Procedure for Attaching the Coin Changer Accessory to the Brewer: (Without a Platform Unit)
The step by step procedure for attaching the coin changer accessory is as follows:
1. Place brewer platform on cabinet top where brewer will be in service. See Figure 3 below.
Figure 3
C
B
A
5
4
3 2
1
Figure 1 Figure 2
