DESCRIPTION OF OPERATING SYSTEM 4-5
615O405A 615O406A
KEY SWITCH
(1) Key Switch (A) Start (B) Heat
(C) On (D) Acc (E) Off
TURN SIGNAL/ HEAD LIGHT SWITCH
(1) Turn Signal Light Switch
(2) Head Light Switch
(A) Right (B) N (C) Left
Turning the light switch one click to C.W.
illuminates the low beam headlights and
taillights.
Next, turning it one more click illuminates
the high beam headlights.
OFF
A key position for stopping the engine.
ACC
A key position for operating accessory
function.
ON
A key position at which the engine is
running.
Heat
A key position for preheating the inside
of the combustion chamber.
Start
A key position for operating the motor.
OFF
Headlight is turned OFF
Low beam headlight is turned ON
Upper beam headlight is turned ON
Direction indication lamp is turned ON
CAUTION
Because of the safety device, the
engine may not be started except
when the clutch is depressed.
This tractor has an automatic pre-heat-
ing system. To pre-heat the engine, turn
the key switch to the “ON” position then
pre-hearting works automatically for 8
seconds. You can see the pre-heating
indicator light on during that time. You can
start the engine at any time during this 8
seconds.
f you need additional pre-heating, turn
the key off and try the same procedure
again or turn the key to “Manual pre-heat”
position and hold it. Do not pre-heat over
15 seconds, more than 10 times without
any break.
When the coolant temperature is over
60°C(140°F) the auto pre-heating does
not work.
In this case, just turn the key to “start” to
crank the engine.
To Next Page
