4-18 DK35/40/450L
615O439B
Differential lock is applied only in cases
where: the wheels are likely to slip, or
only one of the rear wheel slips. Lightly
stepping on the differential lock pedal with
the heel makes the rear wheels run at
equal speed. To unlock, just release the
pedal.
While the Diff. Lock pedal is engaged,
the warning lamp in instrument panel will
light up in the instrument panel.
DIFFERENTIAL LOCK PEDAL
(1) Differential Lock Pedal
(A) Press to “ENGAGE”
(B) Release to “DISENGAGE”
WARNING
zz
zz
z
To prevent loss of control of trac-
tor, never use the differential lock
at speeds above 8 km/h (5 MPH).
zz
zz
z Never use the differential lock
when turning the tractor. When
engaged, the differential lock will
prevent the tractor from turning.
IMPORTANT
zz
zz
z
If a rear wheel spins at speed,
reduce engine speed before en-
gaging the differential lock, to
avoid shock loads to the trans-
mission.
615O438A
MID PTO LEVER
(EXCLUDING DK450L-EU)
(1) MID PTO Lever
CAUTION
To avoid possible injury make
sure the mid PTO is disconnected
(lever down) when not in use.
There is a MID PTO equiped to do various
jobs using implements. If you pull the le-
ver up, it would be connected. On the
other hand if you push it down, it would
be disconnected.
To Next Page
