30
4.4 Spark plug
Inspection/Cleaning:
1) Remove the spark plug cap and remove the spark plug.
2) Remove carbon or other deposits with a plug cleaner or stiff ire brush. Check the sealing
washer for damage.
3) Measure the plug resistance; replace the spark plug if the measure is not accordance with the
specification.
Spark plug resistance 3~9KΩ
4) Measure the plug gap with a feeler gauge. Adjust by bending the side electrode if the reading is
not within the specification..
Spark plug clearance 0.6~0.7mm
Standard spark plug UR5
