31
0.6-0.7
5). Install the plug finger tight to seat the washer, then tighten with a plug wrench.
Torque valve is 13~15 N.m
4.5 Valve clearance
Caution
■ Valve clearance inspection and adjustment must be performed with the engine cold.
Inspection/Adjustment:
1) Remove the following parts:
―Front cover, control panel
―Rear cover
―Right/left side covers
―Fuel tank
―Inverter unit, engine bed
―Recoil starter, fan cover
―Inlet/Exhaust side baffle
2) Remove the four bolts and disassemble the cylinder cover. Don’t remove the valve cover with
excessive force or it will deform. Replace the valve cover if it is deformed.
