Kipor KM2V80 User Manual

4. Specification
Table 1 Main specification table of KM2V80 diesel engine
Model
KM2V80
Type
Double cylinder, V-type, water-cooled, 4 stroke,
swirl type
Bore×Stroke mm
80×79
Displacement L
0.794
Compression ratio
23
Rated output/Rated speed
kW/r/min
12.5/3000
14.5/3600
Max. torque N·m
49/1600～1800
Min. speed (zero load) r/min
≤900
Lubricating system
Pressure splashed
Starting system
Electric starter
Output terminal direction (face
to the flywheel)
Anticlockwise
Fuel type
0#(summer), -10# or -20#(winter), -35#(chillness)
Fuel consumption ratio g/(kW·h)
285
297
Lube oil type
SAE 10W－30、20W－40 or L－ECD Grade
Lube oil capacity L
2.27
oil consumption ratio g/(kW·h)
≤5
Starting motor capacity V，kW
12V 1.4 kW
Charging generator capacity
(V,A)
12V 20A
Battery capacity (V,AH)
12V 60AH
Overall dimension （L×W×H） mm
616×486×528
Net weight kg
58
