TP-6843 12/21 27
Section 3. VSC Controller Operation
3.1 VSC Generator Set Controller
All 6VSG generator sets are equipped with the VSC generator set controller.
The VSC controls generator set and the optional Programmable Interface Module (PIM) or Communications Kit.
The VSC controller features include:
 Two-line x 16 character backlit digital display with adjustable contrast
 OFF, AUTO, and RUN generator set master control buttons
 Generator set status indicating LEDs (OFF, AUTO, RUN)
 Up, Down, and Select buttons for navigation through menus and adjustments
 Power system indicator LEDs to show power output of the generator
3.2 Control and Indicators
Figure 13 illustrates the VSC controller. See Figure 14 for details of the controller’s user interface.
Figure 13 VSC Controls and Indicators
User interface
(see Figure 14)
USB connection
GM89864
