Kohler 6VSG User Manual

34 TP-6843 12/21
3.8 Main Menu
Press the Select button once to bring up the main menu. Overview is displayed. See Figure 19. Press the down arrow button to
step to the next menu, Engine Metering. Use the UP and DOWN arrow buttons to step up and down through the menus shown
in Figure 19.
The controller will exit the main menu after 5 minutes if no buttons are pressed. To exit the main menu immediately, press the
controller’s OFF or AUTO button.
Figure 19 VSC Main Menu
Status
Displays
Press the Up and Down arrow buttons to
move between menus.
Press OFF or AUTO to exit the menus.
Overview --->
1.2 h
Engine --->
Metering
Generator --->
Metering
Genset --->
Information
Genset --->
Run Time
Genset --->
System
Date --->
and Time
Network --->
Information
PIM --->
Status
Event Log --->
