3.17 Programmable Interface Module (PIM) Status Menu
Note:
The PIM status menu appears if a programmable interface module (PIM) or a communications kit interface board (IB) is
connected.
The PIM status menu displays the status of inputs and outputs connected to the programmable interface module (PIM) or
communications kit interface board (IB). See Figure 37. This is a status display menu only. Input and output settings cannot be
changed from the VSC controller’s user interface.
A personal computer running Kohler
®
SiteTech™ software is required to change the input and output settings for the PIM.
Contact an authorized distributor or dealer for service.
The Kohler
®
OnCue
®
Plus Management System can be used to turn the PIM outputs on and off. See the OnCue
®
Plus Software
Operation Manual for instructions.
The input and output settings for the communications kit interface board are factory set and locked.
Figure 37 Programmable Interface Module (PIM) Status Menu
PIM *
Status:
<--- Return
* PIM Status displays the interface board status if the optional communications kit with factory-
installed interface board is installed.
PIM 1 --->
Input 1
In/Active
Input 2
In/Active
Output 1:
In/Active
Output 2:
In/Active
Output 3:
In/Active
Output 4:
In/Active
Output 5:
In/Active
Output 6:
In/Active
<--- Return
