Kohler Command PRO CV682 Service Manual

Specications
6 24 690 37 Rev. BKohlerEngines.com
ENGINE IDENTIFICATION NUMBERS
Kohler engine identication numbers (model, specication and serial) should be referenced for efcient repair,
ordering correct parts, and engine replacement.
Model .....................CV682
Command Engine
Vertical Shaft
Numerical Designation
Specication ...............CV682-0001
Serial .....................4323500328
Year Manufactured Code Factory Code
Code Year
43 2013
44 2014
45 2015
GENERAL SPECIFICATIONS
3,6
CV682 CV732 CV742 CV752
Bore 80 mm
(3.15 in.)
83 mm (3.27 in.)
Stroke 69 mm (2.72 in.)
Displacement 694 cc
(42.4 cu. in.)
747 cc (45.6 cu. in.)
Oil Capacity (rell) 1.6-1.8 L (1.7-1.9 U.S. qt.)
Maximum Angle of Operation (@ full oil level)
4
25°
TORQUE SPECIFICATIONS
3,5
CV682 CV732 CV742 CV752
Blower Housing and Sheet Metal
M5 Fasteners 6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
M6 Fasteners 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Carburetor, Intake Manifold, and Air Cleaner
Intake Manifold to Head Mounting Fastener (torque in 2
increments)
rst to 7.4 N·m (66 in. lb.)
nally to 9.9 N·m (88 in. lb.)
Air Cleaner Nut (torque in 2 increments) rst to 7.3 N·m (65 in. lb.)
nally to 8.2 N·m (73 in. lb.)
Support Bracket to Intake Manifold Fastener 9.9 N·m (88 in. lb.)
Support Bracket to Air Cleaner Housing Fastener 7.9 N·m (70 in. lb.)
Evap Connector Fitting to Air Cleaner Housing HI-LO
Fastener (if equipped) 2.1 N·m (19 in. lb.)
Connecting Rod
Cap Fastener (torque in increments) 13.6 N·m (120 in. lb.)
Crankcase
Breather Cover Fastener 7.3 N·m (65 in. lb.)
Oil Drain Plug 13.6 N·m (10 ft. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
4
Exceeding maximum angle of operation may cause engine damage from insufcient lubrication.
5
Lubricate threads with engine oil prior to assembly.
6
Any and all horsepower (hp) references by Kohler are Certied Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certied Power Ratings can be found at KohlerEngines.com.
