Control Panel Components
O
K
M
B
H
E
D
A
C
I
Q
B
L
G
T
F
J
B
D
N
P
S
R
A Control Bracket B Lock Nut C
Throttle Control
Lever
D Flat Washer
E Throttle Shaft Spring F Throttle Shaft G
Throttle Shaft
Bracket
H
Throttle Control
Lever
I
Governed Idle
Bracket
J Spacer K Governor Spring L Governed Idle Spring
M Governor Lever N Linkage Spring O Throttle Linkage P Air Cleaner Gasket
Q Carburetor R
Carburetor Gasket
(Tab Up)
S Choke Lever T Choke Linkage
Install Carburetor
WARNING
Explosive Fuel can cause res and severe
burns.
Do not ll fuel tank while engine is hot or
running.
Gasoline is extremely ammable and its vapors can
explode if ignited. Store gasoline only in approved
containers, in well ventilated, unoccupied buildings,
away from sparks or ames. Spilled fuel could ignite
if it comes in contact with hot parts or sparks from
ignition. Never use gasoline as a cleaning agent.
1. Use a new carburetor gasket. Make sure tab on
gasket is up.
2. Install carburetor, throttle linkage, and choke linkage
as an assembly. Throttle linkage and choke linkage
should both be assembled from carburetor outward.
3. Connect ground lead and fuel solenoid lead.
Reassembly
6324 690 37 Rev. B KohlerEngines.com
