METHOD FOR STARTING MACHINE (TRAVEL FORWARD AND REVERSE)
AND ST
OPPING MACHINE
METHOD FOR MOVING MACHINE
WARNING
• Before
moving the machine off, check that the area
around the machine is safe, then sound the horn be-
fore starting.
• Keep people away from the machine.
• The area behind the machine is a blind spot. Particu-
larly pay attention when traveling in reverse.
• When moving off the machine on a slope, always keep
decelerator/brake pedal (2) depressed, even after re-
leasing parking brake lever (1).
• When moving off the machine on a steep uphill, turn
fuel control dial (3) to High idle (MAX) position and run
the engine at full speed.
Depress decelerator/brake pedal (2) fully, select 1st
speed, and set joystick (steering, directional and gear
shift lever) (4) to the direction to move off.
Begin to release decelerator/brake pedal (2) gently,
and when the machine moves off slowly (or shoe slip),
release decelerator/brake pedal (2) fully.
• When decelerator/brake pedal (2) is depressed or fuel
control dial (3) is set in Low idle (MIN) position on a
flat ground, the machine is stopped but it does not
mean that brake is applied.
• On slopes, the machine moves even at low idle, so be
extremely careful.
1.
Set parking brake lever (1) to FREE position (F).
2.
Operate joystick (steering, directional and gear shift lever)
(4),
and check that desired speed range is set on the
speed range display of machine monitor (5).
OPERATION MACHINE OPERATIONS AND CONTROLS
3-161
