Komatsu PC4000 User Manual

Assembly Procedure PC4000
PC4000Asrev05
Edition 08/2005
21
2.8 Basic Measurements (Z23038)
2.9 Transport Dimensions and Weights (as example)
(For exact Dimensions and Weights refer to the packing list of your machine.)
Face Shovel Backhoe
L.H. and R.H. Crawler side frame
Track width 1200 mm
Dimensions (mm) 8450 x 2700 x 2420
Weight 52,000 kg / 114,700 lb
L.H. and R.H. Crawler side frame
Track width 1200 mm
Dimensions (mm) 8450 x 2700 x 2420
Weight 52.000 kg / 114.700 lb
Carbody centre
Dimensions (mm) 4420 x 4130 x 2350
Weight 29,000 kg / 64,000 lb
Carbody centre
Dimensions (mm) 4420 x 4130 x 2350
Weight 29.000 kg / 64.000 lb
Counterweight
Dimensions (mm) 6150 x 3420 x 700
Weight 33,800 kg / 75,000 lb
Counterweight
Dimensions (mm) 6150 x 3420 x 700
Weight 33.800 kg / 75.000 lb
Upper-structure main frame
Dimensions (mm) 8420 x 4440 x 3700
Weight 57,500 kg / 126,800 lb
Upper-structure main frame
Dimensions (mm) 8420 x 4440 x 3900
Weight 57.500 kg / 126.800 lb
Main machinery house
Dimensions (mm) 6500 x 3000 x 3300
Weight 30,100 kg / 66,400 lb
Main machinery house
Dimensions (mm) 6500 x 3000 x 3300
Weight 30,100 kg / 66.400 lb
Fuel tank
Dimensions (mm) 2400 x 2100 x 3230
Weight 3.600 kg / 8000 lb
Fuel tank
Dimensions (mm) 2400 x 2100 x 3230
Weight 4.800 kg / 10.600 lb
Hydraulic tank
Dimensions (mm) 2400 x 1200 x 3300
Weight 3.200 kg / 7.100 lb
Hydraulic tank
Dimensions (mm) 2400 x 1200 x 3300
Weight 3.000 kg / 6.700 lb
Cab base
Dimensions (mm) 2280 x 2100 x 3000
Weight 3.400 kg / 7.500 lb
Cab base
Dimensions (mm) 2280 x 2100 x 3000
Weight 2.500 kg / 5.600 lb
Boom 7.15 m with 4 cylinders
Dimensions (mm) 7700 x 2500 x 3200
Weight 34.600 kg / 76.300 lb
Boom 9,75 m with cylinders
Dimensions (mm) 10500 x 2600 x 3700
Weight 32.300 kg / 71.200 lb
Stick 4.9 m without cylinder
Dimensions (mm) 5300 x 2100 x 2000
Weight 14.350 kg / 31.700 lb
Stick 4.50 m with 2 bucket cylinders,
linkage and control arm
Dimensions (mm) 6300 x 1250 x 2400
Weight 26.000 kg / 57.400 lb
21 m³ shovel bullclam bucket bowl
Dimensions (mm) 4100 x 3500 x 3400
Weight 15.350 kg / 33.900 lb
22 m³ SAE backhoe
Dimensions (mm) 3800 x 4200 x 3100
Weight 23.300 kg / 49.300 lb
5 cases with accessories
Dimensions (mm) Weight (kg) Weight (lb)
5780 x 2490 x 1970 5.820 12.900
4000 x 3300 x 3300 5.000 11.100
5800 x 2490 x 1970 6.100 13.500
4900 x 1200 x 1200 4.150 9.200
1660 x 850 x 730 1.000 2.300
1 case oil cooler / 4 cases accessories
Dimensions (mm) Weight (kg) Weight (lb)
5770 x 2490 x 1980 5.500 12.200
3970 x 3290 x 3280 4.950 11.000
5770 x 2490 x 1980 3.450 7.700
4870 x 1090 x 1280 6.400 14.200
5870 x 1290 x 1380 9.300 20.500
