bizhub C658/C558/C458/C368/C308/C258 2-31
2.5 Control Panel
2
About this machine Chapter 2
2.5 Control Panel
The optional Keypad KP-101 is equipped on the right side of the Control Panel.
2.5.1 Name of parts
No. Name Description
1 Touch Panel Displays setting screens and messages.
Directly press this panel to carry out operations.
2 Mobile touch area Used to associate this machine with an NFC-compatible Android ter-
minal.
You can place an Android terminal with Mobile for Android installed
on the mobile touch area to register this machine or to perform user
authentication.
This area is also used to associate this machine with an iOS terminal
that supports Bluetooth LE. The optional Local Interface Kit EK-609
is required to use the Bluetooth LE function.
Bringing the iOS terminal closer to this machine allows you to register
this machine or perform user authentication with an operation from
Mobile for iPhone/iPad.
For details, refer to the User's Guide CD.
3 Access If user authentication or account track is enabled, enter the user name
and password for user authentication or the account name and pass-
word for account track, then press this key to start the use of this ma-
chine. After a target operation is completed, press this key once again
to end the use of this machine.
4 Menu Press this key to display the Main Menu.
5 Reset Press this key to reset the settings you entered or changed on the
Control Panel.
6 Stop Press this key to temporarily stop an active copy, scan, or print job.
7 Start Press this key to start an operation such as copying, scanning, faxing,
or printing.
