Explanation
Dimensions
(Unit: mm)
67.4
79
70
392
253
51
50
47
Filter screw
diameter
ø52
58.5
300
200
Measurement
distance reference
Optical
axis
95.7 229.5
9
Mounting screw M5
Depth 6.5mm
Tripod screw (3/8 inches screw)
Positioning pin hole 1
5
6
Positioning pin hole 2
90
158
190.4
170
ø15
120.5
129
Mounting screw M5
Depth 6.5mm
Depth 10.5 mm
ø5mm Depth 4 mm
Depth 4mm
