3.19 Manual Masking Panels (Option)
1
2
3
4
1
Lengthwise Area Indication Panel
Use to specify the print area in the vertical direction of the image on the
Screen. The system makes a print of the image corresponding to the Area
Keys lit up green. A total of 42 Area Keys are placed at 7-mm intervals.
2
Lengthwise Area Clear Key
Press to clear any print area previously defined in the vertical direction.
3
Crosswise Area Clear Key
Press to clear any print area previously defined in the horizontal direction.
4
Crosswise Area Indication Panel
Use to specify the print area in the horizontal direction of the image on the
Screen. The system makes a print of the image corresponding to the Area
Keys lit up green. A total of 61 Area Keys are placed at 7-mm intervals.
* When 11" x 17" (A3) and Page-by-Page are selected, all Keys light
up except those on the right and left ends. For your information, the
keys on the right and left ends are invalid for the Manual Masking
Panels intended for use in the metric areas.
