3
Scanner
3-37
3.20 Using Manual Masking

NOTE:
Under the PC mode, the print (scan) area can be defined using the
Manual Masking Panels.
The Trimming and Masking functions cannot be used in the PC
mode.
The optional Manual Masking Kit allows you to specify an area for printing
of the displayed image through two separate features, Trimming and
Masking.
Selecting Trimming
1
Press the Masking key to
select
(Trimming).
2
The lights on the panel light
up according to the currently
selected paper size and print
position.
A4 vertical,
Center
ON
Example: A4 vertical, Center
ON

NOTE:
It is possible to print the area specified by the green lights.
The lights which do not accord with the selected paper size and
the print position may light up just after the Job Program is called
up.
