3
Scanner
3-53
3.29 Replacing the Projection Lamp
Use the following procedure to replace the Projection Lamp whenever a
reduction in brightness on the screen is detected or whenever the lamp
burns out. Make sure that the replacement lamp is specified for use with
this scanner.
If the Projection Lamp should burn out during a print operation, an L2 code
will appear and the print job will stop (a blank piece of paper may be output
depending upon the stage of the job).
Once the system detects that the Projection Lamp has burnt out, the scan
job will be cancelled. If the system is operating in the Cycle Print Mode,
the scanning operation will stop.
1
Turn the Power Switch OFF.
CAUTION
§ NEVER touch the lamp with bare hands just after operation or
immediately after turning it OFF.
Wait for at least 10 minutes after shutting the power OFF to allow the
lamp to cool down as it becomes very hot during use.
2
Slide out the Projection
Lamp Unit.
To Next Page
