Start-up
30
Pos: 19.8 /Übersc hriften/Übersc hriften 2/F-J/HH ydrauli k @ 0\mod_1199776 034950_78.docx @ 34205 @ 2 @ 1
6.2 Hydraulics
Pos: 19.9 /Übersc hriften/Übersc hriften 3/P-T/ SSpezielle Sich erheitshinweis e @ 0\mod_119 7301069931_7 8.docx @ 17 662 @ 3 @ 1
6.2.1 Special Safety Instructions
Pos: 19.10 /BA/Sic herheit/Hydr aulik/Warnung - Anschluss der H ydraulikleitu ngen @ 0\mod _1199776548 685_78.doc x @ 34225 @ @ 1
Warning ! - Connection of the hydraulic line
Effect: severe injuries due to penetration of hydraulic oil under the skin.
• When connecting the hydraulic hoses to the hydraulic system of the tractor, the system
must be relieved of the pressure on either side.
• Due to the risk of injury when searching for leaks, always use suitable tools and wear
protective goggles.
• Seek medical help immediately should injuries occur! Danger of infection.
• Depressurise prior to uncoupling the hydraulic hoses and working on the hydraulic system!
• Check the hydraulic hose lines at regular intervals and replace them if damaged or worn!
The replacement hoses must fulfil the technical requirements set by the equipment
manufacturer.
Pos: 19.11 /Übersc hriften/Überschrif ten 3/F-J /HHydraulikleit ungen anschließ en @ 0\mod_ 119977703779 4_78.docx @ 3 4244 @ 3 @ 1
6.2.2 Connecting the hydraulic lines
Pos: 19.12 /BA/Sic herheit/Hydr aulik/WARNUNG - Vertausch en der Hydrauli kkleitungen, wenn EW @ 9\m od_1220871857 985_78.docx @ 128182 @ @ 1
Warning - If the hydraulic hoses are interchanged when connecting them to the
hydraulic system of the tractor, the functions will be interchanged as well.
Effect: Injuries, serious damage to the machine
• Identify the hydraulic connections.
• Always ensure correct connection between the machine and the tractor.
• When engaging the hydraulic hose, the hydraulic control unit must be in float position or in
"lowering" position.
Pos: 19.13 /BA/Sic herheit/Hydr aulik/Achtung - Verschmutzu ng der Hydrauli kanlage @ 2\ mod_120239333 6803_78.docx @ 59155 @ @ 1
Caution! - Soiling of the hydraulic system
Effect: Damages to the machine
• When connecting the quick couplings, ensure that these are clean and dry.
• Note chafing areas or points of contact.
Pos: 19.14 /BA/Sic herheit/Betä tigungsseil/GEF AHR! – Unbea bsichtigte Aktio nen ausgelöst Betätigungsseil verlegen @ 8\ mod_121929 8996457_78.doc x @ 111447 @ @ 1
Danger! - Unintended actions triggered.
Effect: Danger to life, injuries or damage to the machine.
• The actuating rope must be routed in such a way that no movements are unintentionally
triggered in any transport or working positions.
• The actuating rope must not come into contact with the tractor tyres
• Note chafing areas or points of contact.
Pos: 19.15 /BA/I nbetriebnahme/ EasyCut/Hydra ulik/Steuergerä t 1xEW @ 10\ mod_1221486 740745_78.doc x @ 134020 @ @ 1
A single-action control unit is required on the tractor to operate the machine.
Pos: 19.16 /BA/I nbetriebnahme/M ähwerke AM B aureihe/Ansc hluss Hydraulikleit ung AM S / AM CV BAurei he @ 69\mo d_13050924719 35_78.docx @ 6 32836 @ @ 1
• Release the pressure from the hydraulic system on the tractor side
• Insert the hydraulic hose into the hydraulic coupling of the control valve
Pos: 19.17 /BA/I nbetriebnahme/M ähwerke AM Baureihe/B etätigungsseil ableg en AM S und AM CV Baurei he @ 69\mod _130509266217 7_78.docx @ 632864 @ @ 1
• Set down the actuating rope for unlocking the "transport position" at a suitable place in the
tractor cab
