9 Settings

Pos: 27.2 /BA/Sich erheit/7. Gefa hrenhinweise alt /Mähwerke/W arnung - Ei nstellarbeiten ange baute Maschi nen @ 254\m od_1397487875 458_78.doc x @ 1953794 @ @ 1

DANGER! - Unexpected movement of the machine

Effect: Danger to life or serious injuries.

• Setting tasks must only be performed when the drive is switched off and the engine is at a

standstill!

• Switch off engine.

• Remove the ignition key and carry it with you.

• Secure the tractor against rolling away.

Pos: 27.3 /Übersc hriften/Übersc hriften 2/A-E/E Einstellen der Schnitthöhe @ 0\mod_119 6660879619_78.d ocx @ 9191 @ 2 @ 1

9.1 Adjusting the cutting height

Pos: 27.4 /BA/Eins tellungen/Mä hwerke/Schnitt höhe/Schnitthöh e Bild AM 20 3S/243S/283S/3 23S @ 69\ mod_130510469 3672_78.docx @ 633836 @ @ 1

Fig.

Pos: 27.5 /BA/Eins tellungen/Mä hwerke/Schnitt höhe/Schnitthö he größer_g eringer AM 203S/2 43S/283S/3 23S @ 69\mo d_130510483316 4_78.docx @ 6 33924 @ @ 1

The cutting height is adjusted via the top link (1).

To do this:

• Lower the machine into the working position

• Rotate the top suspension arm (1)

Top suspension arm longer = bigger cutting height

Top suspension arm shorter = smaller cutting height
