Maintenance – lubrication chart
63
Pos: 29.36.1 /Üb erschriften/Üb erschriften 1/U-Z/ Wartung - Sc hmierplan @ 0 \mod_119735 9304198_78. docx @ 18232 @ 1 @ 1
11 Maintenance – lubrication chart
Pos: 29.36.2 /Üb erschriften/Üb erschriften 2/P- T/SSpezielle Sic herheitshin weise @ 0\mod_ 11966604957 60_78.docx @ 9 134 @ 2 @ 1
11.1 Special Safety Instructions
Pos: 29.36.3 /B A/Sicherheit/7. G efahrenhinweis e alt/Mähwer ke/Warnung - R eparatur_Wart ung_Reinigungs_ 4 allgemein EasyCut @ 29 2\mod_14109 41423112_78.d ocx @ 2299026 @ @ 1
WARNING!
When performing repair, maintenance or cleaning work or in case of technical
intervention, drive elements may start moving (caution: cutting discs continue to run).
Effect: Danger to life, injuries or damage to the machine.
• Turn off the PTO shaft.
• Move the machine to the working position and lower it to the ground.
• Switch off the engine of the tractor, remove the ignition key and carry it with you.
• Secure the tractor against accidental start-up and against rolling.
• After the repair, maintenance, cleaning work or technical modifications are completed,
mount all protective covers and safety devices properly again.
• Avoid skin contact with oils, greases, cleaning agents and solvents.
• In the event of injuries or burns due to oils, cleaning agents or solvents, contact a physician
immediately.
• All other safety instructions must also be followed to avoid injuries and accidents.
Pos: 29.36.4 /Üb erschriften/Üb erschriften 2/F-J/ GGelenkwelle @ 0\mod_1 19978187979 4_78.docx @ 3454 2 @ 2 @ 1
11.2 PTO shaft
Pos: 29.36.5 /B A/Wartung/Gelen kwelle schmiere n/Abschmiere n Gelenkwelle AM @ 70\m od_13051810 59201_78.doc x @ 635935 @ @ 1
Fig.
Lubricate the PTO shafts at the intervals indicated in the drawing with a multi-purpose grease.
Follow the operating instructions of the PTO shaft manufacturer.
