KTM 1050 Adventure User Manual

22 TROUBLESHOOTING 192
Faults Possible cause Action
Engine turns but does not start Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
Fuel quality is insufficient – Add suitable fuel.
Engine dies during the trip Lack of fuel – Refuel. ( p. 85)
Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
The engine warning lamp lights
up/flashes
Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
The ABS warning lamp lights up ABS fuse is blown – Change the fuses in the fuse box. ( p. 156)
Wheel speeds of front and rear wheels
differ greatly
– Stop, switch off the ignition, start again.
Malfunction in ABS – Read out the fault memory using the KTM diag-
nostics tool.
High oil consumption Engine oil level too high – Check the engine oil level. ( p. 177)
Engine oil too thin (low viscosity) – Change the engine oil and filter, clean the oil
screens. ( p. 178)
The battery is discharged The hazard warning flasher is switched
on
– Switch off the hazard warning flasher.
– Recharge the battery. ( p. 150)
Battery is not charged by alternator – Check the charging voltage.
Ignition was not switched off when
vehicle was parked
– Recharge the battery. ( p. 150)

KTM 1050 Adventure Specifications

General

Displacement	1050 cc
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Bore x Stroke	103 mm x 63 mm
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
ABS	Bosch 9M+ two-channel ABS
Compression Ratio	12.5:1
Starter	Electric
Engine Type	2-cylinder, 4-stroke
Power	95 hp
Torque	107 Nm
Front Suspension	WP USD, 43 mm
Rear Suspension	WP monoshock
Front Brake	4-piston calipers
Rear Brake	267 mm disc, 2-piston caliper
Frame	Chromium-Molybdenum steel trellis
Front Wheel	19 inch
Rear Wheel	17 inch
Dry Weight	212 kg (467 lbs)

Summary

Safety Advice

Use Definition - Intended Use

Defines the intended operational use of the KTM motorcycle for road and light off-road.

Safety Advice

General instructions for safe vehicle operation and awareness of warning labels.

Degrees of Risk and Symbols

Explanation of danger levels (Danger, Warning, Caution, Note) and their symbols.

Tampering Warning

Safe Operation

Guidelines for safe riding, covering intoxication, exhaust hazards, and component temperatures.

Protective Clothing

Emphasizes the importance of wearing protective clothing for riding safety.

Work Rules

Controls

Clutch Lever

Hand Brake Lever

Throttle Grip

Switches on the Left Side of the Handlebar

Light Switch

Hazard Warning Flasher Switch

Menu Switch

Turn Signal Switch

Horn Button

Switches on the Right Side of the Handlebar

Emergency OFF Switch

Function of the emergency OFF switch for interrupting the ignition circuit.

Electric Starter Button

Operation of the electric starter button to start the engine.

Ignition/Steering Lock

Operation of the ignition lock and steering lock mechanism.

Immobilizer

Locking the Steering

Procedure for locking the motorcycle's steering.

Unlocking the Steering

Procedure for unlocking the motorcycle's steering.

Opening the Filler Cap

Closing the Filler Cap

Shift Lever

Foot Brake Lever

Side Stand

Combination Instrument

Overview

Activation and Test

Matrix Display

Segment Display

Indicator Lamps

Meaning of various indicator lamps (e.g., high beam, ABS, engine warning).

Message on the Matrix Display

How warning and status messages are displayed and confirmed.

Shift Warning Light

Service Display

Matrix Display Menu

"Settings"

"Warning"

"MTC/ABS"

"Drive Mod"

"Shift Light"

Ergonomics

Adjusting the Handlebar Position

Adjusting the Wind Shield

Adjusting Basic Position of Clutch Lever

Adjusting the Basic Position of the Hand Brake Lever

Adjusting the Footrests

Checking the Basic Position of the Shift Lever

Adjusting the Basic Position of the Shift Lever

Adjusting the Basic Position of the Foot Brake Lever

Preparing for Use

Advice on First Use

Important safety advice, warnings, and pre-ride checks before the first trip.

Running in the Engine

Guidelines and recommended engine speeds during the break-in period.

Loading the Vehicle

Safety precautions and load limits for carrying luggage or a passenger.

Riding Instructions

Checks and Maintenance Measures When Preparing for Use

Essential pre-ride checks for ensuring the vehicle is roadworthy.

Starting

Step-by-step instructions for starting the engine safely.

Starting Off

Procedure for smoothly moving away from a standstill.

Shifting, Riding

Techniques for gear shifting and general riding advice for control.

Applying the Brakes

Proper techniques and warnings for effective and safe braking.

Stopping, Parking

Procedures for safely stopping the vehicle and parking it.

Transport

Refueling

Instructions and safety precautions for refueling the fuel tank.

Service Schedule

Required Work

Schedule of mandatory maintenance tasks at specified intervals.

Recommended Work

Suspension Setting

Adjusting the Rebound Damping of the Shock Absorber

Procedure for adjusting the shock absorber's rebound damping.

Adjusting the Spring Preload of the Shock Absorber

Procedure for adjusting the shock absorber's spring preload.

Service Work on the Chassis

Lifting the Motorcycle with the Rear Lifting Gear

Removing the Rear of Motorcycle from the Lifting Gear

Lifting the Motorcycle with the Front Lifting Gear

Taking the Motorcycle from the Front Lifting Gear

Raising the Motorcycle with the Work Stand (Inserted)

Removing the Motorcycle from the Work Stand (Inserted)

Removing the Seat

Mounting the Seat

Cleaning the Chain

Checking the Chain Tension

Procedure for checking the tension of the drive chain.

Adjusting the Chain Tension

Procedure for adjusting the drive chain tension.

Checking the Chain, Rear Sprocket, and Engine Sprocket

Checking/Rectifying the Fluid Level of the Hydraulic Clutch

Procedure for checking and correcting the hydraulic clutch fluid level.

Checking the Play of the Steering Head Bearing

Procedure for checking and adjusting steering head bearing play.

Removing the Bottom Triple Clamp Cover

Installing the Bottom Triple Clamp Cover

Removing the Front Side Cover

Installing the Front Side Cover

Removing the Mask Spoiler

Installing the Mask Spoiler

Removing the Front Fender

Installing the Front Fender

Removing the Tank Cover

Installing the Tank Cover

Removing the Wind Shield

Installing the Wind Shield

Removing the Engine Guard

Installing the Engine Guard

Brake System

ABS / Anti-blocking System

Explanation of the ABS system, its function, and limitations.

Checking the Brake Discs

Procedure for checking brake disc thickness, wear, and damage.

Checking the Brake Fluid Level of the Front Brake

How to check the brake fluid level in the front brake reservoir.

Adding Front Brake Fluid

Procedure for adding front brake fluid to the correct level.

Checking the Front Brake Linings

Procedure for checking the minimum thickness of the front brake linings.

Checking the Rear Brake Fluid Level

How to check the brake fluid level in the rear brake reservoir.

Adding Rear Brake Fluid

Procedure for adding rear brake fluid to the correct level.

Checking the Rear Brake Linings

Procedure for checking the minimum thickness of the rear brake linings.

Wheels, Tires

Removing the Front Wheel

Step-by-step instructions for removing the front wheel.

Installing the Front Wheel

Step-by-step instructions for installing the front wheel.

Removing the Rear Wheel

Steps for removing the rear wheel assembly.

Installing the Rear Wheel

Steps for installing the rear wheel assembly.

Checking the Rear Hub Rubber Dampers

Checking the Tire Condition

Inspection of tires for cuts, damage, tread depth, and age.

Checking the Tire Air Pressure

Procedure for checking and adjusting tire air pressure.

Electrical System

Daytime Running Light

Removing the Battery

Safety precautions and steps for safely removing the motorcycle battery.

Installing the Battery

Steps for installing the battery and connecting terminals securely.

Recharging the Battery

Guidelines and procedures for safely recharging the motorcycle battery.

Changing the Main Fuse

Procedure for locating and replacing the main fuse.

Changing the Fuses in the Fuse Box

Procedure for locating and replacing fuses in the fuse box.

Removing the Headlight Mask with the Headlight

Refitting the Headlight Mask with the Headlight

Changing the Low Beam Bulb

Procedure for replacing the low beam headlight bulb.

Changing the High Beam Bulb

Procedure for replacing the high beam headlight bulb.

Changing the Turn Signal Bulb

Procedure for replacing a turn signal bulb.

Checking the Headlight Setting

Procedure for checking the alignment of the headlight beam.

Adjusting the Headlight Range

Procedure for adjusting the headlight beam range.

Activating/Deactivating the Ignition Key

Process for programming, activating, and deactivating ignition keys.

Cooling System

Checking the Coolant Level in the Compensating Tank

Procedure for checking the coolant level in the expansion tank.

Correcting the Coolant Level in the Compensating Tank

Procedure for adding coolant and bleeding the cooling system.

Tuning the Engine

"Drive Mod"

Selecting engine performance and traction control modes (SPORT, STREET, RAIN).

Motorcycle Traction Control (MTC)

Function and operation of the motorcycle traction control system.

Service Work on the Engine

Checking the Engine Oil Level

Procedure for checking the engine oil level using the viewer.

Changing the Engine Oil and Filter, Cleaning the Oil Screens

Steps for changing engine oil, filter, and cleaning oil screens.

Adding Engine Oil

Procedure for adding engine oil to the correct level.

Cleaning, Care

Cleaning Motorcycle

Checks and Maintenance Steps for Winter Operation

Storage

Storage

Preparing for Use After Storage

Troubleshooting

Technical Data

Engine

Engine Tightening Torques

Torque specifications for various engine components.

Capacities

Chassis

Electrical System

Tires

Fork

Shock Absorber

Chassis Tightening Torques

Torque specifications for various chassis components.

Substances

Brake Fluid DOT 4 / DOT 5.1

Coolant

Engine Oil (SAE 10W/50)

Engine Oil (SAE 5W/40)

Fork Oil (SAE 4) (48601166S1)

Hydraulic Fluid (15)

Shock Absorber Fluid (SAE 2.5) (50180751S1)

Super Unleaded (ROZ 95/RON 95/PON 91)
