TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 181

Screw, side stand switch M4 2 Nm (1.5 lbf ft)

Loctite

243™

Remaining chassis screws M5 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –

Screw, fuel tank cover M5 5 Nm (3.7 lbf ft) –

Screw, seat bracket on fuel tank

(Super Duke)

M5 4 Nm (3 lbf ft) –

Nut, tail light (Super Duke) M6 8 Nm (5.9 lbf ft) –

Remaining chassis nuts M6 15 Nm (11.1 lbf ft) –

Remaining chassis screws M6 10 Nm (7.4 lbf ft) –

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, front spoiler M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, fuel tank holder M6 6 Nm (4.4 lbf ft) –

Screw, heel protector M6 2 Nm (1.5 lbf ft)

Loctite

243™

Screw, push rod ball joint on foot brake

cylinder

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift rod M6 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, shift shaft deflector on shift

shaft

M6 18 Nm (13.3 lbf ft)

Loctite

243™

Screw, splash protector, rear wheel M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, spoiler M6 6 Nm (4.4 lbf ft) –

Screw, steering damper pipe clamp

(Super Duke R)

M6 4 Nm (3 lbf ft)

Loctite

243™
