CONTROLS 31

5.22Combination instrument - TRIP F display

400842-01

If the fuel level drops to the reserve mark, the display automatically changes to TRIP F and

starts to count from 0.0, regardless of the previous display mode.

Info

Parallel to the TRIP F display, the fuel warning light switches on.

5.23Combination instrument - ambient temperature display

400893-13

The ambient temperature  is displayed in °C or °F.
