LOCATION OF SERIAL NUMBERS 18

4.4Fork part number

B00155-10

The fork part number  is stamped on the inner side of the fork stub.

4.5Shock absorber part number

B00156-10

The shock absorber part number  is stamped on the top of the shock absorber above the

adjusting ring on the engine side.
