ELECTRICAL SYSTEM 129
13.5Changing the ABS fuses
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are used.
– Use only fuses with the prescribed amperage. Never by-pass or repair fuses.
Info
Two fuses for the ABS are located under the seat. These fuses protect the return pump and the hydraulic unit of the ABS. The third
fuse, which protects the ABS control unit, is located in the fuse box.
– Switch off all power consumers and switch off the engine.
– Remove the seat. ( p. 83)
B00639-10
To change the fuse of the ABS hydraulic unit:
– Take off the protection cap and remove fuse .
– Insert the new fuse.
Fuse (58011109130)
– Check that the ABS warning lamp still lights up.
– Mount the protection cap.
