TECHNICAL DATA - CHASSIS 196

Tail light W5W/socket W2.1x9.5d 12 V

5 W

Brake light P21W/socket BA15s 12 V

21 W

License plate lamp W5W/socket W2.1x9.5d 12 V

5 W

24.2Tires

Front tire Rear tire

120/70 ZR 17 M/C 58W TL

Continental ContiSportAttack

180/55 ZR 17 M/C 73W TL

Continental ContiSportAttack

Additional information is available in the Service section under:

http://www.ktm.com

24.3Capacity - fuel

Total fuel tank capacity, approx. 19 l (5 US gal) Super unleaded (ROZ 95/RON 95/PON 91) ( p. 208)

Fuel reserve, approx. 3.7 l (3.9 qt.)
