TUNING THE ENGINE 162
15.2Adjusting the play in the throttle cable x
B00666-10
– Move the handlebar to the straight-ahead position.
– Use the KTM diagnostics tool to set the throttle stepper motor to the basic position.
– Push back sleeve .
– Loosen lock nut .
– Set the play in the throttle cable by turning adjusting screw .
Guideline
Play in throttle cable 3… 5 mm (0.12… 0.2 in)
– Tighten lock nut .
– Slide on sleeves .
– Check the throttle grip for ease of movement.
15.3Ignition curve plug-in connector
B00667-01
The plug-in connection is located under the seat in front of the tail light.
By disconnecting the plug-in connector, the ignition curve for fuel with an octane rating
below 95 (ROZ 95/RON 95/PON 91) is activated. While the engine will have a slightly
lower power output, this setting prevents engine damage by hindering spark knocking due
to poor fuel quality.
Possible states
• Plug-in connector disconnected – Fuel with an octane rating of 80 to 94 (RON) can be
used for one tank full.
• Plug-in connector connected – Fuel with an octane rating of 95 or higher can be used.
