SERVICE WORK ON THE CHASSIS 88

700633-01

– Remove screws .

– Remove the inside trim of the mask spoiler.

– Repeat the operation on the opposite side.

10.12Installing the mask spoiler

700633-10

– Position the inside trim of the mask spoiler.

– Mount and tighten screws .
