CONTROL
S
51
5.39
Shift
lever
B00120-11
Shift
lever
is
mounted
on
the
left
side
of
the
engine.
B00121-10
The
gear
positions
can
be
seen
in
the
photograph.
The
neutral
or
idle
position
is
between
the
first
and
second
gear.
52
54
Table of Contents
