TECHNICAL SPECIFICATIONS 24
155
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 4.2 N/mm (24 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 4.4 N/mm (25.1 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 4.6 N/mm (26.3 lb/in)
Fork length 940 mm (37.01 in)
Oil capacity, cartridge 175 ml (5.92 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 160)
Oil capacity, external mechanism 390 ml (13.19 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 160)
24.8 Shock absorber
Shock absorber article number A490C463X305000
Shock absorber WP PDS
Lowspeed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Highspeed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 7 mm (0.28 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 66 N/mm (377 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 69 N/mm (394 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 72 N/mm (411 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 38 mm (1.5 in)
Riding sag 110 mm (4.33 in)
Fitted length 402.7 mm (15.854 in)
Shock absorber fluid ( p. 160) SAE 2.5
24.9 Chassis tightening torques
Hose connector, active carbon fil-
ter
- 3.8 Nm (2.8 lbf ft)
Mushroom head screw for spoiler
and seat
2.5 Nm (1.84 lbf ft)
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, emergency OFF switch (All
EXC models)
EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
