12 SERVICE WORK ON THE CHASSIS
81
E00873-12
–
Pull off the air filter box cover in area
A
sideways and take
off toward the front.
12.23 Installing the air filter box cover
E00873-11
–
Insert the air filter box cover in the area
A
and clip it into the
area
B
.
E00873-10
Condition
The air filter box cover is secured.
–
Mount and tighten screw
1
.
Guideline
Screw, air filter box
cover
EJOT PT
®
K60x20-Z
3 Nm (2.2 lbf ft)
12.24 Removing the air filter
Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Never start to use the vehicle without an air filter.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with
the applicable regulations.
Preparatory work
– Remove the air filter box cover. ( p. 80)
