CONTROLS 12
5.9Factory Start (SX‑F ROCZEN REPLICA)
101079-10
The Factory Start 1 is mounted on the right fork protector.
Possible states
• A Factory Start is deactivated – The fork is in the normal operating mode.
• B Factory Start is activated – The fork is compressed and the front of the motor-
cycle is lowered.
By activating the Factory Start, the front of the motorcycle is lowered; this causes the
front wheel to rise up off the ground later during acceleration.
When the fork compresses for the first time, the Factory Start lock button is released
automatically. From this point on, the fork operates as if the Factory Start were deacti-
vated or not installed.
5.10Idle speed adjusting screw
401096-10
Idle speed adjusting screw 1 is located on the throttle valve body at the top left.
The idle speed adjusting screw has two functions.
Turning it controls the idle speed.
Pulling it out all the way raises the idle speed during a cold start.
Possible states
• RPM increase activated – Idle speed adjusting screw is pulled out all the way.
• RPM increase deactivated – Idle speed adjusting screw is pushed in all the way.
5.11Shift lever
100908-10
Shift lever 1 is mounted on the left side of the engine.
100909-10
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
