TROUBLE
SHOOTING
83
Faults
Possible
cause
Action
High
oil
consumption
Piston
and
cylinder
worn
–
Piston/cylinder
-
determine
the
mounting
clear-
ance.
Battery
discharged
Battery
is
not
charging
–
Check
the
charging
voltage.
x
–
Check
the
stator
winding
of
the
alternator.
x
Unwanted
power
consumer
–
Check
the
open-circuit
current.
x
84
86
Table of Contents
Table of Contents
4
Means of Representation
6
Important Information
7
View of Vehicle
9
View of Vehicle, Front Left (Example)
9
View of Vehicle, Rear Right (Example)
10
Serial Numbers
11
Chassis Number
11
Type Label
11
Engine Number
11
Fork Part Number
11
Shock Absorber Part Number
11
Controls
12
Clutch Lever
12
Hand Brake Lever
12
Throttle Grip
12
Kill Switch
12
Electric Starter Button
12
Overview of Indicator Lamps
13
Opening the Filler Cap
13
Closing the Filler Cap
13
Factory Start (SX-F ROCZEN REPLICA)
14
Idle Speed Adjusting Screw
14
Shift Lever
14
Kick Starter (XC-F)
15
Foot Brake Lever
15
Plug-In Stand (All SX-F Models)
15
Side Stand (XC-F)
15
Service Hour Counter (SX-F ROCZEN REPLICA)
16
Preparing for Use
17
Advice on First Use
17
Running in the Engine
18
Preparing the Vehicle for Difficult Riding Conditions
18
Preparing for Rides on Dry Sand
19
Preparing for Rides on Wet Sand
19
Preparing for Rides on Wet and Muddy Surfaces
20
Preparing for Rides at High Temperatures and Low Speeds
20
Preparing for Rides at Low Temperatures or in Snow
20
Riding Instructions
21
Checks and Maintenance before Putting into Operation
21
Starting
21
Starting off
22
Shifting, Riding
22
Applying the Brakes
22
Stopping, Parking
22
Refueling
23
Service Schedule
24
Service Work (as Additional Order)
25
Tuning the Chassis
26
Checking the Basic Chassis Setting with the Rider's Weight
26
Compression Damping of the Shock Absorber
26
Adjusting the Low-Speed Compression Damping of the Shock Absorber
26
Adjusting the High-Speed Compression Damping of the Shock Absorber
27
Adjusting the Rebound Damping of the Shock Absorber
28
Measuring Rear Wheel Sag Unloaded
28
Checking the Static Sag of the Shock Absorber
29
Checking the Riding Sag of the Shock Absorber
29
Adjusting the Spring Preload of the Shock Absorber
29
Adjusting the Riding Sag
30
Checking the Basic Setting of the Fork
31
Adjusting the Compression Damping of the Fork
31
Adjusting the Rebound Damping of the Fork
32
Handlebar Position
32
Adjusting the Handlebar Position
32
Activating the Factory Start (SX-F ROCZEN REPLICA)
33
Service Work on the Chassis
34
Raising the Motorcycle with the Lift Stand
34
Removing the Motorcycle from the Lift Stand
34
Bleeding the Fork Legs
34
Cleaning the Dust Boots of the Fork Legs
35
Loosening the Fork Protection
35
Positioning the Fork Protection
35
Removing the Fork Legs
36
Installing the Fork Legs
36
Removing the Fork Protector
37
Installing the Fork Protector
37
Removing the Lower Triple Clamp
37
Installing the Lower Triple Clamp
38
Checking the Steering Head Bearing Play
39
Adjusting the Play of the Steering Head Bearing
40
Greasing the Steering Head Bearing
40
Removing the Start Number Plate
41
Installing the Start Number Plate
41
Removing the Front Fender
41
Installing the Front Fender
41
Removing the Shock Absorber
41
Installing the Shock Absorber
42
Removing the Seat
43
Mounting the Seat
43
Removing the Air Filter Box Lid
43
Installing the Air Filter Box Lid
43
Removing the Air Filter
44
Installing the Air Filter
44
Cleaning the Air Filter and Air Filter Box
44
Removing the Main Silencer
45
Installing the Main Silencer
45
Changing the Glass Fiber Yarn Filling of the Main Silencer
45
Removing the Fuel Tank
46
Installing the Fuel Tank
47
Checking for Chain Dirt Accumulation
48
Cleaning the Chain
49
Checking the Chain Tension
49
Adjusting the Chain Tension
50
Checking the Chain, Rear Sprocket, Engine Sprocket and Chain Guide
50
Adjusting the Chain Guide
52
Checking the Frame
52
Checking the Swingarm
53
Checking the Throttle Cable Routing
53
Checking the Rubber Grip
53
Additionally Securing the Rubber Grip
53
Adjusting the Basic Position of the Clutch Lever
54
Checking the Fluid Level of the Hydraulic Clutch
54
Changing the Hydraulic Clutch Fluid
54
Removing the Engine Guard (SX-F ROCZEN REPLICA)
55
Installing the Engine Guard (SX-F ROCZEN REPLICA)
55
Brakes
56
Checking the Free Travel of the Hand Brake Lever
56
Adjusting the Basic Position of the Hand Brake Lever
56
Checking the Brake Discs
56
Checking the Front Brake Fluid Level
57
Adding Front Brake Fluid
57
Checking the Front Brake Linings
58
Changing the Front Brake Linings
58
Checking the Free Travel of Foot Brake Lever
60
Adjusting the Basic Position of the Foot Brake Lever
60
Checking the Rear Brake Fluid Level
61
Adding Rear Brake Fluid
61
Checking the Rear Brake Linings
62
Changing the Rear Brake Linings
62
Wheels, Tires
64
Removing the Front Wheel
64
Installing the Front Wheel
64
Removing the Rear Wheel
65
Installing the Rear Wheel
66
Checking the Tire Condition
66
Checking the Tire Air Pressure
67
Checking the Spoke Tension
67
Electrical System
69
Removing the Battery
69
Installing the Battery
69
Recharging the Battery
70
Changing the Main Fuse
71
Cooling System
72
Checking the Antifreeze and Coolant Level
72
Checking the Coolant Level
72
Draining the Coolant
73
Refilling Coolant
73
Tuning the Engine
75
Checking the Play in the Throttle Cable
75
Adjusting the Play in the Throttle Cable
75
Adjusting the Idle Speed
75
Checking the Basic Position of the Shift Lever
76
Adjusting the Basic Position of the Shift Lever
76
Service Work on the Engine
77
Changing the Fuel Screen
77
Checking the Engine Oil Level
78
Changing the Engine Oil and Oil Filter, Cleaning the Oil Screen
78
Adding Engine Oil
80
Cleaning, Care
82
Cleaning the Motorcycle
82
Storage
83
Putting into Operation after Storage
83
Troubleshooting
84
Blink Code
86
Technical Data - Engine
87
Capacity - Engine Oil
88
Capacity - Coolant
88
Technical Data - Engine Tightening Torques
89
Technical Data - Chassis
91
Lighting Equipment
91
Tires
92
Capacity - Fuel
92
Technical Data - Fork
93
All SX-F EU Models
93
Sx-F Usa
93
XC-F
94
Technical Data - Shock Absorber
95
All SX-F EU Models
95
Sx-F Usa
95
XC-F
96
Technical Data - Chassis Tightening Torques
97
Substances
98
Auxiliary Substances
100
Standards
102
Index
103
