KTM 390 DUKE 2024 User Manual

COMBINATION INSTRUMENT 7
27
7.10 Speed limiter display (optional)
I00502-10
The operating status of the activated speed limiter is shown in dis-
play area
1
.
The speed limiter is controlled using the combination switch.
Info
If the speed limiter function is switched on but the speed
limiter is not active, the speed limiter indicator lamp lights
up yellow.
When the speed limiter function is switched on and the
speed limiter is active, the speed limiter indicator lamp
lights up green.
7.11 Time
I00501-11
The time is shown in area
1
of the display.
The time can be displayed in 24-hour format or 12-hour format in
all languages.
The format of the time can be configured in
the Clock Format menu.
Info
The time must be reset if the 12-V battery was discon-
nected from the vehicle or the fuse was removed.
7.12 Ride‑Mode display
I00501-13
The Ride Mode ( p. 100) setting is shown in area
1
of the dis-
play.
The drive mode can be configured in the Ride Mode submenu.
7.13 ABS display
I00501-14
The ABS mode setting is shown in the
1
area of the display.
ABS can be configured separately in the ABS submenu.
Info
When the ABS mode Road is active, ABS controls both
wheels.
When the Supermoto ABS mode is active, ABS only controls
the front wheel. The rear wheel is not controlled by ABS
and may lock during braking maneuvers.

KTM 390 DUKE 2024 Specifications

General

Displacement	399 cc
Compression Ratio	12.6:1
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Steel trellis frame, powder coated
Rear Suspension	WP APEX Monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Wheelbase	1, 357 mm ± 15 mm
Seat Height	820 mm
Engine Type	Single-cylinder, 4-stroke
Power	44 hp
Torque	39 Nm
Clutch	PASC anti-hopping clutch, mechanically operated
Front Suspension	WP APEX 43 mm
Front Brake	4-piston radial fixed caliper, 320 mm disc
Rear Brake	Single-piston floating caliper, brake disc
ABS	Bosch 9.1MB
Fuel Tank Capacity	13.4 liters
Instruments	TFT display
Lighting	LED
Riding Modes	Street, Rain
