23 TECHNICAL DATA
148
23.2 Engine tightening torques
Oil jet, piston cooling M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle for clutch lubrication M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle for timing chain lubrica-
tion
M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle, piston cooling M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle, rocker arm lubrication M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Pulse generator screw and cable
retainer
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, bearing retainer M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft)
Screw, gear position sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, suction pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, water pump impeller M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 10 Nm (7.4 lbf ft)
Screw, bearing bolt, torque limiter M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, camshaft support plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, EVAP plug M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, pressure pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain tensioner M6 10 Nm (7.4 lbf ft)
